2 Hp 155 Psi V-style Single Stage Cast Iron Air Compressor

• Cast iron cylinders for durability and long life
• Automotive style ball bearings and stainless steel reed valves for increased durability
• Pleated air filter with metal canister for efficient and durable filtration
• Aluminum head and finned cover for better heat dissipation
• Uses A-width, V-style belt (not included)
• 11.4 oz. oil reservoir (oil not included)
• 155 PSI max working pressure
• 5.3 SCFM @ 90 PSI
• 1300 RPM max
• When pump runs at 1300 RPM. Requires A-width, V-style belt, not included

Enhance your compressor’s performance with the 2 HP, 155 PSI, 1-Stage V-Style Cast Iron Air Compressor Pump. Built for durability and efficiency, this pump is a perfect replacement for most 120V, 2 HP compressors, including DEWALT, PORTER-CABLE, and SANBORN models. It fits a 6-3/4" x 3-9/16" bolt pattern and includes compression fittings for 3/8" or 1/2" outlet tubes, plus extra gaskets for easy maintenance. Designed for motor pulleys ranging from 3.6" to 3.85". Upgrade your compressor today for reliable performance!

• Brand: MCGRAW
• Model: MG2HPSS
• Flow Rate: 6.2 SCFM @ 40 PSI, 5.3 SCFM @ 90 PSI
• Accessories Included: 3/8 in. & 1/2 in. compression fittings, extra gaskets
• Compatible With: 120v, 2HP DEWALT, PORTER-CABLE, SANBORN, POWERMATE, MAGNA FORCE and INDUSTRIAL air compressors
• Horsepower: 2
• Material: Cast iron, aluminum
• Maximum Pressure: 155 PSI
• Speed (max.): 1300 RPM
• Product Height: 12-1/4 in.
• Product Length: 13-1/2 in.
• Product Weight: 32.7 lb.
• Product Width: 10-3/4 in.
• Shipping Weight: 35.52 lb.
• Stroke Length: 1.82 in.
• Sound Rating: 86 dB
